- Piston Area (in²): 3.00
- Piston Type: Stainless
- Dust Boot: No
Rotor Dimensions:
- Rotor Width (in): 1.00
- Rotor Diameter(in): 13.06
Pad Dimensions:
- Pad Area (in²): 6.36
- Pad Volume (in³): 2.1
Duty Rating & Material:
- Material: Forged Aluminium
- Weight(Lbs): 3.8
Colors & Finish:
- Color: Black
- Finish: Black Powder Center(in): 5.25
- Mount Side: Universal
- Mount Type: Lug
Rotor Compatibility:
- Rotor Width (in): 1.00
- Maximum Rotor Width (in): 1.04
- Minimum Rotor Width (in): 0.94
- Maximum Rotor Diameter(in): 13.06
- Minimum Rotor Diameter(in): 10.00
Piston Specifications:
- Piston 1 Bore (in): 1.38
- Piston 2 Bore (in): 1.38
- Total Piston Area (in²): 3.00
Mounting Specifications:
- Mount Type: Lug
- Mount Side: Universal
- Mount Center(in): 5.25
- Mount Hole Size(in): 0.39
- Mount Height(in): 2.10
- Inlet Thread Size: 1/8-27 NPT
SHIPPING
- We do our best to ship most items same or next day.
- For all products, free fast delivery of the UPS is already included in the price.
- Unfortunately UPS doesn’t accept PO box address. Please specify physical address which will guarantee faster delivery.
PAYMENT
- All orders must be paid via PayPal.
- You may use your paypal dollars, or use your MC/Visa, Amex, Discover thru your PayPal account.
RETURNS
- We offer 30 Day return policy.
- Buyer pays return shipping.
- Returns will only be accepted with a valid RMA number.
- All returns must be in original box unopened.
- A 20% restocking fee may apply.
- All products returned are assumed to be in new and saleable condition unless the customer indicates otherwise at the time of submission. Re-boxing fees will be assessed on items received with damaged packaging. This fee may include shipping or other charges levied by the manufacturer. Any product returned in damaged, used or otherwise unsaleable condition may be returned to the customer or credit given at lower value, at the discretion of Autoshopping24.
EXCHANGE OF FAULTY ITEMS
- Unfortunately mistakes happen and very seldom we ship faulty items. If you would like to get a replacement for an item purchased from us, we can do it for you! Please ship the original item(s) to our warehouse first and provide us with tracking number(s). Once we see that items are on their way we will send a replacement.
OVERVIEW
Dynapro Lug Mount
The DynaPro Lug Mount (DP) forged billet caliper represents the newest generation of calipers available as an upgrade or replacement for applications previously using the long-standing Dynalite model series. DP calipers combine pure race technology with several new exclusive Wilwood performance enhancements. A sleek profile with superior strength and a fully detail machined finish provide the performance and looks for competition or show.
The strength of the DynaPro is a combination of process and design. The DynaPro is stress-flow forged from premium grade billet. Stress-flow forging realigns the grain structure of the metal within the contour of the body design. This process produces a part with superior strength over parts simply machined from straight grained blocks of billet. The FEA generated body design incorporates a highly fortified radial transition that eliminates steps and shoulders between the piston housings and the bridges. Incorporating a radius in this critical area substantially increases resistance to deflection and caliper body separation under load. Structural deflection and volume displacement testing have proven the efficiency of this innovative design. Reductions in overall deflection, and the subsequent decreases in fluid volume displacement, translate to increased clamping efficiency with less pedal travel. The bottom line is a firm, responsive pedal with outstanding stopping power.
The DynaPro is loaded with other enhancements for performance and wider application. The calipers feature Quick-E-Clip pad retainers that support a 7812 type brake pad from the top. Not only does it allow for fast pad service without caliper removal, the bottom pad supports have been removed to create a slimmer profile that can be more easily fitted into tight clearance applications.
VEHICLE APPLICATIONS
Street Rods Heavy Duty
Street Performance Domestic Heavy Duty
Street Performance Import Heavy Duty
Rally Medium Duty
Road Race Medium Duty
Late Model Dirt STARS, UMP, IMCA, etc... Heavy Duty
Drag Racing Heavy Duty
Northeast Modified Dirt or Pavement Medium Duty
Open Wheel Sprint, Midget, etc… Dirt or Pavement Medium Duty
Off Road Medium Duty
Industrial Medium Duty
NOTES
Heavy wall stainless steel pistons are used to resist corrosion and slow the heat transfer from the pads. The heavy wall sectional thickness also provides additional strength against backside deflection to provide a firm pedal feel and efficient clamping, even at the high pressures generated by power boost systems.
For additional strength, all DP calipers can be fitted with a center bridge bolt kit to provide even greater resistance against body separation under high load. Center bridge bolts are included with all side inlet \"SI\" models and available as an upgrade option on all other models.
If you have fitment questions or concerns, please contact us prior to ordering.
