Application：
Bigger HP Applications, perfect for all 4/6 cylinder and 2.5L-6.0L engines
Capable of Boosting Horse Power up to 600HP
for Honda K20, H22, F22 Engines
for Nissan SR20DET, RB20/25,
for Toyota 1JZ/2JZ, 7MGTE.
Also Works for Twin Turbos Applications for SBC, for LSx,
for Ford 4.6, 5.0 Engines
Note : This is universal application turbo, so modification might be required for some vehicles.
Please confirm that there is enough space in your car to install this turbo before purchasing.
Product Specific：
Turbine Side:
Exhaust Inlet Flange: T3 Flange
Exhaust Outlet Flange: 4-Bolt
Turbine Trim: 84.2
Turbine A/R: 0.63
Turbine Inducer Diameter: 68mm
Turbine Exducer Diameter: 62.4mm
Compressor Side:
Compressor Trim: 56.9
Compressor A/R: 0.7
Compressor Inducer Diameter: 61.5mm
Compressor Exducer Diameter: 81.5mm
Compress Inlet Size(Air intake): 4 inch (103.5mm)
Compressor Outlet Size: 2.5 inch (63.6mm)
Bearing Type:Floating/Journal Bearing
Thrust bearing:270 degree
Cooling Type:Water + Oil Cooling
Horse Power:Up to 600HP
Turbo Type:Individual
Wastegate:W/O Wastegate
Oil Inlet:M10*7/16-24
Oil Outlet:M14.1 & 2*M8*1.25
Water:M14*1.5
Maximum PSI:22
Condition:100% Brand New
Accessories:You will get exactly as shown as picture above
Pakage Size:26 x 25 x 23 cm
Product Material:
1. Turbine housing : iron QT450-10 shell
2. Steel Turbine Wheel: K418 alloy
3. Compressor housing: ZL104 aluminum
4. compressor wheel/blades: Cast precautions：
Professional installation is strongly recommended, and requires professional guidance or replacement from a repair shop. It is not suitable for personal installation and requires a large number of accessories.
Product Description Original Quality, Restore Your Vehicle's Power This turbo turbocharger ensures perfect compatibility and installation with original parts, requiring no modifications. Note: Please lubricate the turbocharger and gaskets with oil before use. Professional installation is highly recommended.
The turbo charger's impeller and compressor wheels undergo dynamic balance testing, significantly reducing wear and extending service life. This process minimizes vibrations and noise during operation, ensuring a smoother driving experience.
The impeller is made from K418 nickel-based cast alloy, a high-temperature resistant material that maintains optimal performance even under sustained high temperatures, prolonging the engine turbocharger's lifespan.
This turbocharger with gasket kit improves boost efficiency, resulting in enhanced engine power output and faster throttle response, giving your vehicle the performance edge it needs.
The turbocharger housing is made from high-strength ductile iron, delivering excellent performance in high-temperature resistance, durability, and lifespan. The precisely engineered housing ensures proper sealing and avoids leaks.
Features & Details
- Precision OEM Fit: This turbocharger with gasket kit is specifically designed for vehicles with 2.5L-6.0L engines. NOTE: Please verify your vehicle specifications and compatibility. Professional installation is highly recommended.
- Heat Resistance Materials: The turbo turbocharger features a ductile iron housing, capable of withstanding temperatures up to 800-1000℃. This ensures reliable performance and stability even under extreme temperatures.
- Dynamic Balance Tested: The turbo charger undergoes dynamic balance testing to ensure smooth operation of the compressor wheel and impeller, significantly reducing wear, extending service life, minimizing noise, and providing a quieter, more comfortable driving experience.
- K418 Turbine Wheel: The turbocharger kit's impeller is made from K418 nickel-based cast alloy, providing excellent high-temperature strength and oxidation resistance, enhancing the durability and efficiency of the impeller.
- Restore Engine Performance: Our high-quality and durable engine turbocharger allows you to quickly replace faulty parts, restore engine responsiveness, reduce abnormal noise, and extend the life of your vehicle.
