Features
- Genuine RIGID Industries 360 Connect light bar, SKU 36308
- 40" modular light bar assembly
- 24,480 raw lumens
- 200.2W, 14.3A at 14V
- Combination Spot + Drive optics
- Includes four 4" 360 RGBW Spot pods
- Includes four 4" 360 RGBW Drive pods
- RGBW backlighting with 7 selectable backlight colors
- Modular design allows straight or curved configuration
- Billet aluminum connect bar and rugged construction
- 9–36 VDC operation
- Designed for off-road use
- No center support required with the 360 Connect design
Description
The RIGID Industries 36308 360 Connect 40" Light Bar Assembly combines eight 4" 360-Series LED pods into a powerful modular lighting system. The assembly uses four Spot pods for long-range illumination and four Drive pods for broader coverage, producing a total of 24,480 raw lumens.
The 360 Connect system can be configured in either a straight or curved arrangement. RGBW backlighting provides multiple color options for the rear illumination, while the billet aluminum modular construction is designed for demanding off-road applications. IndustriesSeries360 ConnectModel / SKU36308Light Bar Size40"Light Pods8 × 4" 360-SeriesSpot Pods4Drive Pods4Beam PatternSpot + Drive / ComboRaw Lumens24,480Power200.2 WCurrent Draw14.3A @ 14VVoltage9–36 VDCRGBW BacklightYesBacklight lbUPC849774036712ApplicationOff-road / universal applications
Specifications are from RIGID's product information.
What's Included
- Pre-assembled 40" light bar
- (4) 4" 360 RGBW Spot lights
- (4) 4" 360 RGBW Drive lights
- Mounting hardware
- Light assembly harness
- (8) black light covers
Important: RIGID lists the L-shaped mounting brackets, part #36314, as sold separately, while its product page also notes harness availability separately; verify your actual package before listing the harness as included.
Suggested Item Specifics
- Brand: RIGID Industries
- Type: LED Light Bar
- Lighting Technology: LED
- Light Color: White / RGBW Backlight
- Beam Type: Combo
- Size: 40"
- Wattage: 200.2W
- Voltage: 9–36V
- MPN: 36308
- Lumens: 24,480
- Series: 360 Connect
