Specification:OE number:13533166
Replacement: Direct Bolt-On Replacement
Condition: 100% Brand New
Type:Tire pressure sensor
Manufacturer Warranty:3 Years
Fitment Type:Direct Replacement
Number of Pieces:4NOTE:Pls make sure that the OE Number:13533166 and the item picture fit your car before Chevrolet Silverado 1500
2022-2024 GMC Sierra 1500
2023-2024 GMC Sierra 2500 HD
2023-2024 GMC Sierra 3500 HD
2023-2024 Chevrolet Silverado 2500 HD
2023-2024 Chevrolet Silverado 3500 HD
2022-2024 Cadillac Escalade
2021-2024 Chevrolet Tahoe
2021-2024 Chevrolet Suburban
2021-2024 GMC YukonInstallation Process:
Loosen the tire: Remove the valve cap and core and deflate the tire.
Dismount the tire: Clamp the tire onto the tire changer, and adjust the valve at 1 o’clock relative to the tire separation head. Insert the tire tool and lift the tire bead onto the mounting head to discount the head.
Dismount the sensor: With a screwdriver remove the fastening screw and sensor from the Valve stem, then loosen the nut and remove the valve.
Mount sensor and valve: Slide the valve stem through the valve hole of the rim. Tighten the screw-nut with 4.0 Nm with the help of the positioning pin. Assemble the sensor body against the rim and tighten the screw.
Mount the tire: Place the tire on the rim, making sure that the valve faces the separation head at an angle of 180 degrees. Mount the tire over the rim.
