The UAZEH10A is a 10 kW Electric Heat Kit (Heat Strip Assembly) specifically designed for residential GE / GE Appliances ducted air handling units (AHUs) and multi-position heat pump systems.Technical Specifications
Capacity:
10 kW nominal heating capacity (roughly 34,120 BTU/hr of supplemental or emergency heat).
Electrical Rating:
Designed for 208V / 240V, single-phase (1\\phi), 60 Hz systems.
Built-in Protection:
It features an integrated 60A circuit breaker acting as both a local disconnect at the air handler and overcurrent protection for the high-amperage element load.
Compatibility:
It is commonly dropped into GE ducted air handler chassis sizes ranging from 2-ton up to 5-ton units (such as the UUY24, UUY36, UUY48, and UUY60 series).
