SpecificationsModel: L40Speed Control: F5-R3Motor Type: Brush MotorRated Voltage(V): 12Rated Speed(R/min): 1700Rated Current(A): 34Rated Power(W): 408Control Handle: RetractableMaximum Speed(km/h): 6Noise: 50dbUltimate Thrust: 300kg/661 lbsBattery Model: 12V 100A BatteriesNet Weight: 10kg/22lbsGross Weight: 11.8kg /26lbsPropeller Model: 3 LeavesPropeller Diameter: 24.13cm/9.5inRod Length: 83.82cm/33inchProduct Length: 101.6cm/40inClaping Space: 2-6cm/0.8-2.4inTotal Length of Handle: 48.26-62.23cm/19-24.5inPacakge Size: 101*43*16cm (39.76*16.93*6.3inch)Fishing Boat Engine Outboard Electric Trolling Motor 40LBS 12V Short Shaft 40cm
Application
The trolling motor is suitable for a variety of small watercraft, such as fishing boats, dinghies, and inflatable L40
Speed Control: F5-R3
Motor Type: Brush Motor
Rated Voltage(V): 12
Rated Speed(R/min): 1700
Rated Current(A): 34
Rated Power(W): 408
Control Handle: Retractable
Maximum Speed(km/h): 6
Noise: 50db
Ultimate Thrust: 300kg/661 lbs
Battery Model: 12V 100A Batteries
Net Weight: 10kg/22lbs
Gross Weight: 11.8kg /26lbs
Propeller Model: 3 Leaves
Propeller Diameter: 24.13cm/9.5in
Rod Length: 83.82cm/33inch
Product Length: 101.6cm/40in
Claping Space: 2-6cm/0.8-2.4in
Total Length of Handle: 48.26-62.23cm/19-24.5in
Pacakge Size: 101*43*16cm (39.76*16.93*6.3inch)
Package Included
1*Trolling Motor
1*Power Propeller
1* Circuit Breaker Protector
1*Battery Clamp
1 Set of Screws
1*English Manual
Notes
1. Please read the attached manual completely before use. And pay particular attention to the safety instructions included.
2. Don\'t start the motor on the bank. If you want to test the motor, it should be done in the river.
3. Don\'t use the motor when no water comes out of it, and then check whether the pump impeller or the water outlet is blocked.
4. Do not switch gears too quickly. You should switch from one gear to another.
5. Be sure the switch is in the OFF position before the connection to the battery.
6. Always disconnect power when replacing the propeller, removing debris around the propeller, charging batteries, transporting a boat, or when the motor is not in use.
7. Remember always disconnect from batteries once the motor leaves water as a rotating propeller can cause personal injury.
8. Electrical arcing near the battery could ignite hydrogen gas and cause the battery to explode.
9. Please wash the motor with freshwater, so that it can greatly reduce the possibility of corrosion.
10. All trolling motors have noise. And the noise of this motor is the same as a motorcycle, which is normal.
11. The trolling motor is recommended for thrusting small boats under 200kg/440lbs.
12. You must prepare a boat motor bracket or lifting board on your boat.
13. The battery is not included in the package.
14. Please choose 12V 100A battery so that the maximum power can be guaranteed for 3 hours of continuous operation.
15. Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
Cylinder Scoring is a serious damage,which caused by improper use and will cost you a lot of money to repair the motor.
Don\'t do the following will avoid cylinder Scoring:
1，start the motor on bank
2, use the motor when it stop coming out of water
Even if you want test the motor, it should be done in the river!
When there is no water coming out from the motor,please stop using it immediately ,then check the impeller of Water pump or check if the water outlet has been blocked.PaymentDelivery detailsTerms of salesAbout usContact usPaymentWe accept payment 。Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer\'s responsibility.Delivery detailsShipping:2-9 working days to: USATerms of sales
