1970-1972 Pontiac GTO 400 / 455 Non-Ram Air Master Engine Bolt Kit by AMK Products.
AMK Part Number: 70T-STD
This OEM-correct master engine hardware kit is designed for 1970-1972 Pontiac GTO 400 and 455 non-Ram Air applications.
The kit contains factory-style engine bolts, screws, studs, nuts, washers and specialty fasteners with correct-style head markings and finishes where applicable.
Each sub-kit is individually bagged and labeled by application for easier identification and installation during restoration.
KIT INCLUDES
Air Cleaner, 67 HO & RA / 68-69 Standard / 69H HO — 4.12\" Long Stud and Chrome Wing Nut
Air Cleaner Heat Stove Pipe — 3/8-16 Hex Nuts
Carburetor, Rochester 4V — Hex Bolts
Carburetor Choke Thermostat — Hex External SEMS
Crank Damper — Hex Bolt and Heavy Flat Washer
Crank Pulley — 5/16-24 x 3/4\" Place Bolts
Dipstick Tube to A/C Compressor Brace — Hex Washer AB Screw and Spring Nut
Distributor — Hex Split SEMS Machine Screws
Engine Block Plugs — 1/8-27 Hex Plugs
Engine Fan to Clutch — 5/16-18 x 5/8\" Place Bolts
Fan Clutch to Water Pump — Double-Ended Studs and Hex Nuts
Exhaust Manifolds, Standard 350 / 400 / 455 — Hex Bolts and Steel Locks
Exhaust Pipe to Manifolds, Standard — 1.62\" Hex Bolts
Fuel Pump — 5/16\" Hex Bolts and Vulcanized Aluminum Washers
Ignition Coil & Strap — Hex Washer AB Screw, Slotted Round Machine Screw and Spring Nut
Ignition Wire & Miscellaneous Brackets — Hex Bolts
Intake Manifold, Iron with 4 Studs — Hex Flange Bolts, Hex Collar Studs and Flat Washers
Oil Filter Assembly to Block — Hex Bolts, Split Washers and Flat Washer
Oil Pan — Hex Washer Machine Screws with Correct \"W\" Head Marking in Round Indent
Throttle Bracket to Intake — Hex Bolt, Hex Nut and Flat Washer
Timing Cover — Hex Bolts, Studs, Dowels, Washers and Clamp
Valve Covers with Iron Intake — Silver Zinc-Chromate Hex Washer Machine Screws with Correct \"W\" Head Marking in Round Indent
Water Neck — Hex Bolt, Hex Collar Stud and Flat Washers
Water Pump — Place Bolts, Hex Bolts and Washers
VEHICLE APPLICATION
1970-1972 Pontiac GTO400 / 455 EnginesNon-Ram Air Applications
OEM-correct restoration hardware with factory-style head markings and finishes where applicable.
Individually bagged and labeled AMK sub-kits.
Please verify engine and non-Ram Air application before ordering.
New AMK Products restoration hardware.
