***Please NOTE: item no longer comes with oil temp gauge.Oil temp gauge has been replaced with digital clock.***
This Digital Dash comes complete with direct fit printed circuit boards, custom fit "smoked" Plexiglas face plates, universal temperature sending unit, oil pressure sending unit, and speedometer sending unit (sender/sensor) for trucks without electronic transmission or cruise control, and instructions. The Digital Dash works with your factory fuel level sending unit and cruise control sender or electronic transmission output if so equipped. Everything fits directly into your existing housing, but you may need some additional 18-gauge wire.
Unit is single wire hook up and NOT PLUG & PLAY.
1963-1967 Corvette LED Digital Gauge Panel - DP2000
Look fabulous in your 1963-67 Corvette with Intellitronix direct fit 63-67 Corvette LED Digital Gauge Replacement Dash Panel. The 1963-67 Corvette LED Digital Panel comes complete with direct fit printed circuit boards, custom fit "smoked" plexiglass faceplate, universal temperature sending unit, oil pressure sending unit, and speedometer sending unit with senders and sensors for vehicles without electronic transmission or cruise control, and instructions for installation.
Speedometer reads up to 255 MPH and features odometer, trip meter, one-button calibration, regardless of tire size, gear ratio, or transmission, and 0-60 time, 1⁄4 mile elapse time, and high speed recall, all with the push of a button. The speedometer can be used with electronic cruise control senders or use included S9013 universal speedometer sending unit, if your vehicle is not equipped with a functional cruise control.
Tachometer has a 0-9999 readout in 100, 10, or 1 RPM increments (ex. 9900, 9990, 9999).
Water Temperature display reads 100-300°F range and includes sending unit S8013. Please add a note at checkout if you need a 3/8" bushing, because we send the more common 1/2" bushing. Otherwise, you will have to purchase the bushing on your own.
Oil Pressure reads 0-100 PSI range. Oil pressure sending unit is included.
Voltmeter displays 7.0-25.5 volts range and no sending unit required.
Fuel Level displays Empty to Full in 1/4 increments and works with existing GM fuel level sending unit.
The panel features turn signals and high beam indicator making it the ultimate way to keep the ride you love cruising through the times.
The 63-67 Corvette replacement panel features a custom-designed LED digital, is microprocessor-controlled with peak rpm memory recall, automatic night dimming and RPM activated switch that handles 3 amps. Red is best for night driving.
Easy Install, Lifetime Warranty, Great Price and Gauges for your very special classic vehicle.
BEZEL NOT INCLUDED
Know Before You Buy!
If you have a LS engine, then please be aware that you may need adapters (metric to nonmetric) for our sending units. You may have to obtain them elsewhere separately, though they may have been included with your engine kit, so you may already have them. Also, if your LS engine is 4-cylinder, then please make a note at checkout letting us know, so that we can set the tachometer accordingly. The tachometer is programmable, you can set it yourself if it comes set differently.
·Know Before You Buy!
If you have an LS engine, then please be aware that you may need adapters (metric to nonmetric) for our sending units. You may have to obtain them elsewhere separately, (Part Number 8014-LS / LS Swap Kit). Also, if your LS engine is 4 cylinders, then please send a note to the seller letting us know, so that we can set the tachometer accordingly. The tachometer is programmable, you can set it yourself if it comes set differently.
We always strive to be sure that your order is accurate to meet your specific requirements. With that in mindplease try to make any special requests in "BUYERS NOTES" at checkoutwhen placingyour order.The buyer’s notes are the section that many customers put make, model, year of vehicle etc... but it is also used to make special requests like LS or KM/H & Celsius etc...
The Order Processing Department and Customer Service Department (e-bay messages) are separate. Depending upon our volume of messages to be answered, any special requests made via messages instead of an added “BUYERS NOTE” with order, could be missed before your order ships. We try to catch them all and coordinate with both departments but sometimes the timing can be off.
RETURN POLICY
·The panel kit comes with a Lifetime Guarantee and is made in the USA!
·If you're not 100% completely satisfied, then just arrange to send it back within the 30-DAY return period.
After the initial 30 days from purchase date, all warranty and service-related requests are done directly with the manufacturer of product (Intellitronix). Keep proof of purchase and keep installation guide with all related contact information such as phone number of MFG for warranty requests or technical assistance.
