JE FSR Pistons Eagle H Beam Rods Honda Prelude H22 H22A1 H22A4 87.5mm 9.0:1 CR
Description 298732: Must Sleeve Block. Can Not be used with Stock FRM Cylinder Walls. / CRS5630H3D: H22A H22A1 H22A4
These pistons are +0.50mm (or 0.020 inches) over bore. This is often referred to as \"Twenty Thou Over\". Many times when an engine is being rebuilt after a failure, the cylinder walls are slightly damaged, requiring the clinder hole to be bored out. This process removes any surface irregularities from the cylinder wall, exposing a clean true surface. This oversized piston is used to make up the specified difference of material removed by boring the hole bigger. Consult with your machine shop to determine what diameter your engine will be required to be bored to, then buy the corresponding oversized piston. JE has lead the Piston market since the very beginning. All of the big boys making noise in the industry right now use JE because of their superior design and strength. This is a top of the line piston that one would use to build the ultimate street engine or a reliable race engine. All pistons come balanced within one gram, include pin lock grooves, rings, and wrist pins at no additional charge.Eagle Rods have been the most popular rod choice for most engine builds since our fathers were out racing. For years they have been a reliable cost effective rod solution that exceed the requirements of 90% of the people we talk to. They have the best availability in the business with excellent quality control and customer service. ARP Rod bolts are a standard feature. If you are unsure if this is the correct rod for you, please contact one of our experienced sales reps today to help you put together the parts list for your next build!
Note: 298732: Must Sleeve Block. Can Not be used with Stock FRM Cylinder Walls. / CRS5630H3D: H22A H22A1 H22A4
Car Make: Honda
Car Model: 298732: Prelude / CRS5630H3D: Prelude H22A H22A1 H22A4
Engine: 298732: H22A1 H22A4 / CRS5630H3D: H22A H22A1 H22A4
Included Ring Set: JG1004-3445
Old Part Number: 253988
Torque Specs: 43 ftlbs with ARP moly lube on threads
Compression Ratio: 9.0:1
Pin Fit: Bushed
Small End Width: 0.940
Thickness Above Pin: 0.200
Dome CC: -6.2
Rod Journal: 1.889
Recommended Rod Bearings: CB1780
Head CC: 53.8
Rod Bolt: 3/8\" ARP 2000
Part Weight: 298732: 321 / CRS5630H3D: 520
Big End Width: 0.935
Beam Type: H-Beam Rods
Pin Size: 0.866
Compression Height: 31
Rod Length: 298732: 143 / CRS5630H3D: 5.630
Stroke: 90.7
Bore: 87.5
Material: 2618
Bore Size: 0.5
Standard Pin (Included): 866-2250-15-51C
Pin Locks (Included): 866-063-MW
Manufacturer Product Specifications JE has lead the Piston market since the very beginning. All of the big boys making noise in the industry right now use JE because of their superior design and strength.Eagle Rods have been the most popular rod choice for most engine builds since our fathers were out racing. For years they have been a reliable cost effective rod solution that exceed the requirements of 90% of the people we talk to. Payment Almost all of our items are \"Buy it Now\" which means payment is due immediately at the time of purchase.
