SAME DAY SHIPPING1X8091
- QUALITY - Easy to identify part number permanently engraved on the rubber. 4.5 - 5.00 mm thick rubber that exceeds OEM requirements. 25% stronger 4140 grade steel studs. Stronger composite pistons. Highest leak test ratio after final assembly.
- SPECS - Extended Height: 19.00\" // Compressed Height: 6.10\" // Top Plate Width: 11.31\" // Piston Width: 10.10\" // Weight: 20.50 lbs
- REPLACEMENT FOR - Hendrickson Trailer S-20901, S-21784, C-20901 C-21784 // Intraax AA250T (reuse metal disk) Van Traax HKA-250 (reuse metal disk) // Goodyear 1R14-171 // Firestone W01-358-8091 // Triangle AS-8523 // Automann 566.ER8091 // AS8091, HDV8091, HD8091 // Sampa SP558091-KP
AIR SPRING RL PB
Air Spring Type:Rolling Lobe
Base Plate Material:Aluminum
Bottom Plate Alignment:Parallel
Bottom Plate Bolt Hole Quantity:1
Bottom Plate Center to Center:2.25 Inch
Bottom Plate Diameter:10.16 Inch
California Proposition 65:Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Design Height:10 Inch
Load Rating at 100 PSI:10250 Pound
Load Rating at 80 PSI:8200 Pound
Maximum Diameter:10.62 Inch
Maximum Height:19 Inch
Minimum Height:6.1 Inch
Natural Frequency:74 Hertz
Taxonomy A:Air Springs/Bags
Taxonomy B:Trailer
Taxonomy C:Rolling Lobe
Top Plate Bolt Hole Quantity:2
Top Plate Center to Center:5.5 Inch
Top Plate Diameter:11.31 Inch
Warranty Period:1 Year or 100,000 Miles
Replaces:
- Batco:10-98091
- Goodyear:1R14-171
- Dayton Parts:308-257
- Dayton Parts:352-8091
- Dayton Parts:452-8091L
- Firestone:8091
- Triangle Air Springs:8523
- Triangle Air Springs:AS-8523
- Euclid:E-FS8091
- Freightliner:FI W01 358 8091
- Meritor:FS8091
- Navistar:GY1R10171
- Hendrickson:HKA250
- Meritor:R202009
- Meritor:RFS8091
- Hendrickson:S-20127
- Hendrickson:S-20901
- Hendrickson:S-21784
- Genuine Newstar:S-44718
- Hendrickson:S20901
- Hendrickson:S21784
- Genuine Newstar:S44718
- Firestone:W01-358-8091
- World American:WA01-8091
