T04E T3/T4 .57 A/R 57 TRIM TURBO COMPRESSOR 400+HP BOOST STAGE III Charger For Sale - New and Used


T04E T3/T4 .57 A/R 57 TRIM TURBO COMPRESSOR 400+HP BOOST STAGE III Charger
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.


Buy Now

T04E T3/T4 .57 A/R 57 TRIM TURBO COMPRESSOR 400+HP BOOST STAGE III Charger:
$105.99

T04E T3/T4 .57 A/R 57 TRIM TURBO COMPRESSOR 400+HP BOOST STAGE III Charger
T04E T3/T4 .57 A/R 57 TRIM TURBO COMPRESSOR 400+HP BOOST STAGE III Charger

Fit for:

This item fits: Universal Application ( Modification might be required for some vehicles )
Compatible for 1.5L to 2.5L any 4/6 cylinder engine
Maximum PSI 18(1.2Bar)

Specific:

Turbine Intake Flange: T3 T4 4 bolt Flange Patterns
Turbine Exhaust Flange: Standard T3 5 bolt flange pattern
Wastegate: External Wastegate
Compressor Trim: 48.1
Compressor A/R: 0.5
Compressor Inducer: 52.7mm
Compressor Exducer: 76mm
Turbine Trim: 74.2
Turbine A/R: 0.57
Turbine Inducer: 64.8mm
Turbine Exducer: 55.8mm
Turbine exhaust inlet: 45mm/87mm
Compressor outlet: 42mm(inside diameter)、52mm(Outer diameter)
Compressor inlet: 68 mm(inside diameter)、77mm(Outer diameter)

Cooling Type: Oil Cooled
Bearing Type: Floating Bearing/Journal Bearing
Trust Bearing: 270 degree
Hosepower: Up to 400+HP
Turbo Type: Individual
Universal Fitment: Yes
Finish: Matte
Condition: Brand New
Product Size:23x 22x 18 cm
Package Weight: 7620g

Key Features:

*Product Material
1. Turbine housing: Ductile iron QT450-10 - temperature resistant up to 700℃
2. Steel turbine wheel: K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing: L104 aluminum with lightweight
4. Compressor wheel/blades: Cast aluminium blades – superior air tightness & corrosion resistance

*Product Performance
1. Cost-effective turbo increase 20-40% power for your car
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance
4. Built for durability and strength

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer

Tips before installing:
1.Replace the air filter: if the if the air filter is not replaced may cause the compressor wheel damage.
2.Replace the engine oil: Because floating bearing and turbocharger will be damaged by impurities in the old oil.
3.After large overhaul, the engine cannot be replaced with a new turbocharger because there are too much impurities in oil after overhauling which will damage the replacement turbocharger immediately. Please run the old turbocharger for 7-10 days and then replace to new turbocharger and new engine oil.

NOTE:

* Replace, repair or reconnect air cleaner element per manufacturer's manual to avoid compressor wheel damage.
* Make sure the oil drain line is lower than the turbo itself.
* Ensure exhaust outlet are well sealed by welding
* The degree of modification of the universal turbo depends on your individual vehicle.
* Professional installation is highly recommended.
* This Turbo is not vehicle specific. Please check the specifications and verify compatibility prior to placing your order.
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!

Identify your your turboShipping

US Domestic Shipping Notice - All items will be dispatched within 24hrs(Mon-Fri)

Our carrier collects all the parcels at 4:30am PDT, any payment paid after 5:00am PDT will be shipped the next day at 4:30am PDT.

Otherwise your shipment will be deferred. We are not responsible for any shipping lost caused by wrong shipping informationresponseWarranty

We aim to provide you the good buying experience, 30 days return policy is offered in our store. Please follow our return policy before you return any item(s):


If you are unhappy with your purchase for any reason, you can return it to us in an un-used condition in the original packaging within 30 days of purchase and we'll give you a refund or exchange. Please note you MUST contact us to obtain a Return Authorization Number before returning any part. Any parcel without the Return Authorization Number will be rejected.


If your item is faulty or was incorrect, you must contact our sales representative before returning the parcel and we will endeavour to solve the problem effectively. Video or picture is required to show the item condition before we issue the Return Authorization Number.


Important notice:

1. Any returned item(s) without Return authorization number will be rejected.

2. Please return your item(s) in original packaging and ensure that all packages are securely wrapped

3. We will not accept responsibility for loss or damage of goods during transit, please ensure that the insurance cover option is taken where possible

4. Upon receipt, all products will be inspected at our discretion in 3-5 business days. Then, the updated result will be informed.


If you have made a mistake on purchase and wish to cancel the order before it is dispatched please contact us by massages or email as quickly as possible.


FAQ

Will this fit my car?

We have used the compatibility list as a guide for buyers to use, but the data system is not accurate and incomplete sometimes. Please make sure you have read through the whole listing and paid attention to “note” and “notice”. If there is any uncertain, please use the message to check with our sales first.


How much does delivery cost and how long will it take?

You can check the delivery cost in the listing “Shipping and payments” section by selecting your country and entering your zip code. If it is not specified, please provide us your shipping address and zip code via message. For US domestic shipping to 48 states, the delivery time is around 3-5 business days. The international shipment delivery time is around 4-7 business days.


What payment methods do you accept?

We currently only accept payment via PayPal. You can also use PayPal as a guest and pay using a debit or credit card.


When will my order be dispatched?

We will arrange the shipment in 1 business day after the payment is cleared. The tracking number will be updated on in 24 hours after the shipment. Please notice that there is no shipment during weekend and holidays.


Can I amend my order?

Sorry no. Once the payment is cleared, we cannot amend any item(s), quantities, or add or remove items. We are also unable to change the delivery address. Therefore, please double check all the order information before making payment.


What do I do if I have not received my order?

Please simply contact us via messages, and then, we will get back to you as soon as possible with the update. Usually, we will follow up every shipment till customers get their order.


What do I do if my product is faulty?

Please simply contact us via messages, and then, we will get back to you as soon as possible. It will speed up the process if you could provide us some pictures or video to illustrate the issue details.
